MECHANICAL

Dimensions
Length: 50.95 mm (2.0 in)
Width: 30 mm (1.2 in)
Thickness: 4.76 mm (0.19 in)

ENVIRONMENTAL

Operating Temperature
-20°C to 60°C (-4°F to 140°F)

Storage Temperature
-40°C to 70°C (-40°F to 158°F)

Humidity
25 °C to 60 °C, 0% to 95% relative humidity, noncondensing

Shock
2400 g, 0.5 msec, 6 times each axis

Vibration
10 to 500 Hz, 1 grms, in 3 axis

Drop Survival
Tested to withstand 6-foot drop, (1.8 meter) per MIL-STD 810G when packaged into Intermec handheld computer

POWER

Operating Voltage
2.8 to 5.2 VDC

Read Current
1.3 Amps, typical (3.8V) @ 30 dB

Standby Current
30 mA (3.8V)

Deep Sleep Current
100 microamps

MICROPROCESSOR

ams AS3993

FREQUENCY RANGE

860-928 MHz, regional dependent
